Nextgen Steel & Alloys is a highly appreciated manufacturing company of Threaded Outlet. We supply our products in domestic and international markets. Our company offers only high performance, high quality, and longer life Threaded Outlet. First, we discus about Outlets.
Outlets are alternative to piping branch connections. In old days, whenever branch connection was required, piping cut pieces were welded onto the main pipeline, and for strength again, an additional reinforcement pad will be welded on it. Outlet offers an alternate means of connecting into the main run and does not require reinforcement. Outlets are pre-shaped to the curvature on the run pipe. There are different types of Outlets like socket, weldoutlet, Threaded Outlet, elboutlet, nipoutlet, etc. We are experts in the manufacturing of Threaded Outlet. Threaded Outlet is a 90-degree branch connection. It also comes with a threaded end connection. Threaded Outlet also comes in full size and reducing size. The end connection of Threaded Outlet is ideal for the threaded joint. In our company, this outlet is available in flat-based to use branch connections in pipe caps and vessel heads. Mostly, Threaded Outlet is used for small size piping with a low-pressure application.
MSS-SP 97 Threding Outlet Exporter, Duplex Steel Threaded Outlet, Nickel Alloy Threaded Outlet, 6000# Threaded Outlet, ASME B16.11 Threaded Outlet, 3000LB Threaded Outlet, Stainless Steel Threding Branch Outlet, Alloy Steel Threaded Outlet, Carbon Steel Threaded Outlet, Threaded Outlet Supplier In India.
These Threaded Outlets are offered in different sizes, standards, specifications, dimensions, and as per customer requirements. Our company offers these Threaded Outlets that are suitable for work in high temperature and high pressure applications. This Threaded Outlet has good tensile strength and yield strength. It also has high corrosion resistance properties. Further, it provides better oxidation cubing power and has good creep strength. Apart from this, Threaded Outlet has good mechanical properties and good toughness even at the down to the cryogenic temperatures. Also, it has very good workability and good weldability. This Threaded Outlet is useful to various application industries such as Pulp and Paper, Chemical Plant, Power Generation, Food Processing, Oil and Gas, Pharmaceutical, Marine, Petrochemical Processing, Construction, and so many.
Other Outlet Products:
Standard Specifications for Threaded Outlet
Dimensions
ASME B16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799
Size
1/8″ to 4″
Thickness
Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Connect Type
Welded, threaded, BW, SW
Threaded Outlet Materials and Grade:
Stainless Steel Threaded Outlet :
ASTM A182, F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L, SMO 254
Duplex & Super Duplex Steel Threaded Outlet :
ASTM / ASME A/SA 182 F44, F45, F51, F53, F55, F60, F61 / Duplex 2205 – UNS S31803, UNS S32205 / Super Duplex 2507 – UNS S32750, UNS S32760
Carbon Steel Threaded Outlet :
ASTM/ ASME A105, ASTM/ ASME A350 LF2, ASTM A694 & ASME SA694 F42 / F46 / F52 / F56 / F60 / F65 / F70
Alloy Steel Threaded Outlet :
ASTM / ASME A182 F5 / F9 / F11 / F12 / F22 / F91, 1 1/4 CR, 2 1/4 CR, 5 CR, 9CR, 91
Inconel Threaded Outlet : ASTM B564, Inconel 600 – UNS No. N06600, Inconel 601 – UNS No. N06601, Inconel 625 -UNS No. N06625, Inconel 715, Inconel 718 – UNS No. N07718, Incoloy 800 / 800H /800HT – (UNS No. N08800 / N08810 / N08811), Incoloy 825 – UNS No. N08825, Incoloy 925 – UNS No. N09925
Hastelloy Threaded Outlet :
ASTM B/SB564, Hastelloy B2 – UNS No. N10665, Hastelloy B3 – UNS No. N010675, Hastelloy C4 – UNS No. N06455, Hastelloy C22 – UNS No. N06022, Hastelloy C276 – UNS No. N10276, Hastelloy C2000 – UNS No. N06200, Hastelloy X – UNS No. N06002
Nickel Threaded Outlet : Nickel 200 – UNS No. N02200 , Nickel 201 – UNS No. N02201
Monel Threaded Outlet :
ASME SB 564, Monel 400 – UNS No. N04400, Monel K500 – UNS No. N05500
Titanium Threaded Outlet :
ASTM B381 / ASME SB381, Grade 2 – UNS No. R50400, Grade 5 – UNS No. R56400
Alloy 20 Threaded Outlet :
ASTM B462 / ASME SB462 – UNS No. N08020
Contact us to get quote for your requirement.
Threaded Outlet Dimensions
| MSS SP-97 Threaded Outlet Dimensions | ||||||||||
| Branch Nominal Size | Length | OD of Fitting | OD at End of Branch | Length of Thread | Cut Hole Dia. | |||||
| DN | NPS | 3000 | 6000 | 3000 | 6000 | 3000 | 6000 | 3000 | 6000 | |
| 6 | 1/8 | 19 | 27 | 22 | 6.7 | 16 | ||||
| 8 | 1/4 | 19 | 27 | 22 | 10.2 | 16 | ||||
| 10 | 3/8 | 21 | 30 | 25 | 10.4 | 19 | ||||
| 15 | 1/2 | 25 | 32 | 38 | 45 | 33 | 42 | 13.6 | 24 | 19 |
| 20 | 3/4 | 27 | 37 | 47 | 52 | 39 | 48 | 13.9 | 30 | 25 |
| 25 | 1 | 33 | 40 | 56 | 63 | 48 | 58 | 17.3 | 36 | 33 |
| 32 | 1 1/4 | 33 | 41 | 66 | 72 | 58 | 67 | 18 | 45 | 38 |
| 40 | 1 1/2 | 35 | 43 | 75 | 83 | 64 | 77 | 18.4 | 51 | 49 |
| 50 | 2 | 38 | 52 | 90 | 104 | 77 | 93 | 19.2 | 65 | 59 |
| 65 | 2 1/2 | 46 | 105 | 94 | 28.9 | 76 | ||||
| 80 | 3 | 51 | 124 | 114 | 30.5 | 94 | ||||
| 100 | 4 | 57 | 154 | 140 | 33 | 121 | ||||
Threaded Outlet Available Inventory
Threding Outlets In Mumbai
High Nickel Alloy Threaded Outlet Supplier
MSS-SP 97 Threaded Outlet Exporters
Super Duplex Steel Threaded Outlets
Austenitic Stainless Steel Threaded Outlet
9000LB Threaded Outlet Stockist
Suppliers of ASME B16.11 Threding Outlet
Threding Outlet Fittings Exporter
Hastelloy Alloy Threaded Outlet
Super Duplex Steel Threaded Outlet Manufacturer
ANSI B16.11 Inconel Threaded Outlet
Alloy 20 Threaded Outlet Supplier in India
ASTM A182 SS Threaded Outlet
Copper Nickel Threaded Outlet Stockholder
Titanium Threaded Outlet in India
Threaded Outlet at Best Price
Searches Related to Threaded Outlet
duplex steel uns s31803 / s32205 Threaded Outlet, buy Threaded Outlet class 9000, Threaded Outlets supplier in india, Threaded Outlet price in india, Threaded Outlet exporters, incoloy 825 Threaded Outlet, super duplex steel s32760 Threaded Outlet, high pressure forged Threaded Outlet manufacturer, Threaded Outlet near me, Threaded Outlet dimensions sch-160, 70/30 cu-ni Threaded Outlet, Threaded Outlet class rating, 316 ss Threaded Outlets, copper nickel 90/10 Threaded Outlet, monel 400 Threaded Outlet stock, Threaded Outlet connection, sdss s32750 Threaded Outlets, Threaded Outlet 3000 lbs, alloy 201 Threding outlet, Threaded Outlet dimensions mss-sp 97, Threaded Outlet mss sp 97, hastelloy alloy c276 Threaded Outlet in india, ltcs Threaded Outlet in mumbai, Threaded Outlet price, Threaded Outlet branch connection, gr 5 titanium Threaded Outlet trader in india, Threaded Outlet manufacturer in india, ansi/asme b16.11 Threaded Outlet supplier in mumbai, 9000# Threaded Outlet distributors, Threaded Outlet in india, inconel 600 Threaded Outlet wholesaler, Threaded Outlet suppliers near mumbai maharashtra, saf 2507 Threding outlet, hastelloy c22 Threaded Outlet supplier, nickel 200 Threaded Outlet stockists, pipe outlet Threaded Outlet, inconel 625 Threaded Outlet, Threaded Outlet manufacturer in mumbai, Threding outlet branch fittings, Threaded Outlet b16.11, incoloy 800 Threaded Outlet, Threaded Outlet dimensions chart, astm a105 Threaded Outlet, Threaded Outlet pressure rating, ss 304 / 304l Threaded Outlet stockholder, class 3000 Threaded Outlet, stainless steel 316l Threaded Outlet, Threaded Outlet price list in india, dss 2205 Threding outlet fitting, low temperature carbon steel Threaded Outlet, titanium grade 2 Threaded Outlets dealers, Threaded Outlet dimensions.
Application of Threaded Outlet
